A versatile, high-performance Change Data Capture (CDC) engine built in Rust.

⚠️ Status: Active development. APIs, configuration, and semantics may change.

DeltaForge streams database changes into downstream systems like Kafka, Redis, and NATS - giving you full control over routing, transformation, and delivery. Built-in schema discovery automatically infers and tracks the shape of your data as it flows through, including deep inspection of nested JSON structures.

DeltaForge is not a DAG based stream processor. It is a focused CDC engine meant to replace tools like Debezium when you need a lighter, cloud-native, and more customizable runtime.

Quick Start

Get DeltaForge running in under 3 minutes:

# pipeline.yaml
apiVersion: deltaforge/v1
kind: Pipeline
metadata:
  name: my-first-pipeline
  tenant: demo
spec:   source:     type: mysql     config:       id: mysql-src       dsn: ${MYSQL_DSN}       tables: [mydb.users]
processors: []
sinks:     - type: kafka       config:         id: kafka-sink         brokers: ${KAFKA_BROKERS}         topic: users.cdc

docker run --rm \
  -e MYSQL_DSN="mysql://user:pass@host:3306/mydb" \
  -e KAFKA_BROKERS="kafka:9092" \
  -v $(pwd)/pipeline.yaml:/etc/deltaforge/pipeline.yaml:ro \
  ghcr.io/vnvo/deltaforge:latest \
  --config /etc/deltaforge/pipeline.yaml

helm install deltaforge ./deploy/helm/deltaforge \
  --set secrets.create=true \
  --set secrets.data.MYSQLUSER=cdcuser \
  --set secrets.data.MYSQL_PASSWORD=s3cret

sinks:   - type: kafka     config:       id: kafka-sink       brokers: ${KAFKA_BROKERS}       topic: users.cdc       envelope:         type: debezium

The Tech

| Built with | Sources | Processors | Sinks | Encodings | Output Formats | |:---:|:---:|:---:|:---:|:---:|:---:| | Rust | MySQL · PostgreSQL | JavaScript · Outbox · Flatten · Filter | Kafka · Redis · NATS · HTTP | JSON · Avro | Native · Debezium · CloudEvents |

Features

• Sources

• Schema Registry

• Schema Sensing

• Checkpoints

• Dead Letter Queue

• Processors

• Sinks

Event Output Formats

DeltaForge supports multiple envelope formats for ecosystem compatibility:

| Format | Output | Use Case | |--------|--------|----------| | native | {"op":"c","after":{...},"source":{...}} | Lowest overhead, DeltaForge consumers | | debezium | {"schema":null,"payload":{...}} | Drop-in Debezium replacement | | cloudevents | {"specversion":"1.0","type":"...","data":{...}} | CNCF-standard, event-driven systems |

🔄 Debezium Compatibility: DeltaForge uses Debezium's schemaless mode (schema: null), which matches Debezium's JsonConverter with schemas.enable=false - the recommended configuration for most Kafka deployments. This provides wire compatibility with existing Debezium consumers without the overhead of inline schemas (~500+ bytes per message).

💡 Migrating from Debezium? If your consumers already use schemas.enable=false, configure envelope: { type: debezium } on your sinks for drop-in compatibility. For consumers expecting Avro with Schema Registry, configure encoding: { type: avro, schemaregistryurl: "http://sr:8081" } — DeltaForge produces the standard Confluent wire format.

See Envelope Formats for detailed examples and wire format specifications.

Documentation

• 📘 Online docs:
• 🔒 Guarantees & Correctness — delivery tiers, ordering model, transaction boundaries, failure isolation, retry behavior
• ⎈ Helm Chart — Kubernetes deployment with StatefulSet, PVC, ServiceMonitor
• 🛠 Local: mdbook serve docs (browse at )

Local development helper

Use the bundled dev.sh CLI to spin up the dependency stack and run common workflows consistently:

./dev.sh up     # start Postgres, MySQL, Kafka, Redis, NATS from docker-compose.dev.yml
./dev.sh ps     # view container status
./dev.sh check  # fmt --check + clippy + tests (matches CI)

See the Development guide for the full layout and additional info.

Container image

Pre-built multi-arch images (amd64/arm64) are available:

# From GitHub Container Registry docker pull ghcr.io/vnvo/deltaforge:latest

From Docker Hub
docker pull vnvohub/deltaforge:latest
Debug variant (includes shell)
docker pull ghcr.io/vnvo/deltaforge:latest-debug

Or build locally:

docker build -t deltaforge:local .

Run it by mounting your pipeline specs (environment variables are expanded inside the YAML) and exposing the API and metrics ports:

docker run --rm \
  -p 8080:8080 -p 9000:9000 \
  -v $(pwd)/examples/dev.yaml:/etc/deltaforge/pipelines.yaml:ro \
  -v deltaforge-checkpoints:/app/data \
  deltaforge:local \
  --config /etc/deltaforge/pipelines.yaml

or with env variables to be expanded inside the provided config:

# pull the container docker pull ghcr.io/vnvo/deltaforge:latest

run it
docker run --rm \
  -p 8080:8080 -p 9000:9000 \
  -e MYSQL_DSN="mysql://user:pass@host:3306/db" \
  -e KAFKA_BROKERS="kafka:9092" \
  -v $(pwd)/pipeline.yaml:/etc/deltaforge/pipeline.yaml:ro \
  -v deltaforge-checkpoints:/app/data \
  ghcr.io/vnvo/deltaforge:latest \
  --config /etc/deltaforge/pipeline.yaml

The container runs as a non-root user, writes checkpoints to /app/data/df_checkpoints.json, and listens on 0.0.0.0:8080 for the control plane API with metrics served on :9000.

Architecture Highlights

Delivery Guarantees

DeltaForge supports end-to-end exactly-once (Kafka transactions), at-least-once with server-side dedup (NATS), and at-least-once with consumer-side dedup (Redis). Checkpoints are saved only after sink acknowledgement — never before.

Each sink maintains its own independent checkpoint. The fastest sink is never held back by the slowest. On restart, the source replays from the minimum checkpoint across all sinks.

Source → Processor → Sinks (deliver concurrently) → Policy check → Per-sink checkpoints

Transaction boundaries are preserved: all rows from one database transaction appear in the same batch and are delivered atomically to each sink (respectsourcetx: true by default).

📘 Full details: Guarantees & Correctness

Schema-Checkpoint Correlation

The schema registry tracks schema versions with sequence numbers and optional checkpoint correlation. During replay, events are interpreted with the schema that was active when they were produced - even if the table structure has since changed.

Source-Owned Schemas

Unlike tools that normalize all databases to a universal type system, DeltaForge lets each source define its own schema semantics. MySQL schemas capture MySQL types (bigint(20) unsigned, json), PostgreSQL schemas preserve arrays and custom types. No lossy normalization, no universal type maintenance burden.

API

The REST API exposes JSON endpoints for liveness, readiness, and pipeline lifecycle management. Routes key pipelines by the metadata.name field from their specs and return PipeInfo payloads that include the pipeline name, status, and full configuration.

Health

• GET /health - lightweight liveness probe returning ok.
• GET /ready - readiness view returning {"status":"ready","pipelines":[...]}

Pipeline management

• GET /pipelines - list all pipelines with their current status and config.
• POST /pipelines - create a new pipeline from a full PipelineSpec document.
• GET /pipelines/{name} - get a single pipeline by name.
• PATCH /pipelines/{name} - apply a partial JSON patch to an existing pipeline

• DELETE /pipelines/{name} - permanently delete a pipeline.
• POST /pipelines/{name}/pause - pause ingestion and processing for the pipeline.
• POST /pipelines/{name}/resume - resume a paused pipeline.
• POST /pipelines/{name}/stop - stop a running pipeline.

Schema endpoints

• GET /pipelines/{name}/schemas - list DB schemas for the pipeline.
• GET /pipelines/{name}/sensing/schemas - list inferred schemas (from sensing).
• GET /pipelines/{name}/sensing/schemas/{table} - get inferred schema details.
• GET /pipelines/{name}/sensing/schemas/{table}/json-schema - export as JSON Schema.
• GET /pipelines/{name}/sensing/schemas/{table}/classifications - get dynamic map classifications.
• GET /pipelines/{name}/drift - get drift detection results.
• GET /pipelines/{name}/sensing/stats - get schema sensing cache statistics.

Configuration schema

Pipelines are defined as YAML documents that map directly to the internal PipelineSpec type. Environment variables are expanded before parsing, so secrets and URLs can be injected at runtime.

metadata:
  name: orders-mysql-to-kafka
  tenant: acme
spec:   sharding:     mode: hash     count: 4     key: customer_id
source:     type: mysql     config:       id: orders-mysql       dsn: ${MYSQL_DSN}       tables:         - shop.orders         - shop.outbox       outbox:         tables: ["shop.outbox"]       snapshot:         mode: initial
processors:     - type: javascript       id: my-custom-transform       inline: |         function processBatch(events) {           return events;         }       limits:         cpu_ms: 50         mem_mb: 128         timeout_ms: 500
sinks:     - type: kafka       config:         id: orders-kafka         brokers: ${KAFKA_BROKERS}         topic: orders         envelope:           type: debezium         encoding: json         required: true         exactly_once: false     - type: redis       config:         id: orders-redis         uri: ${REDIS_URI}         stream: orders         envelope:           type: native         encoding: json      batch:     max_events: 500     max_bytes: 1048576     max_ms: 1000     respectsourcetx: true
commit_policy:     mode: quorum     quorum: 2
schema_sensing:     enabled: true     deep_inspect:       enabled: true       max_depth: 3     sampling:       warmup_events: 50       sample_rate: 5     high_cardinality:       enabled: true       min_events: 100

Roadmap

• [x] Outbox pattern support
• [x] Flatten processor
• [x] Filter processor
• [x] Persistent schema registry (SQLite, then PostgreSQL)
• [x] Snapshot/backfill (initial load for existing tables)
• [x] HTTP/Webhook sink
• [x] Dead letter queue with per-event routing
• [x] Per-sink independent checkpoints
• [x] Exactly-once delivery (Kafka transactions)
• [x] Avro encoding with Confluent Schema Registry
• [x] Helm chart for Kubernetes deployment
• [ ] S3/Parquet sink
• [ ] MongoDB source
• [ ] Event replay from DLQ journal
• [ ] Kubernetes operator (PipelineTemplate + PipelinePool)
• [ ] Protobuf encoding

License

Licensed under either of

• MIT License (see LICENSE-MIT)
• Apache License, Version 2.0 (see LICENSE-APACHE)

Unless you explicitly state otherwise, any contribution intentionally submitted for inclusion in this project by you shall be dual licensed as above, without additional terms or conditions.
