Zentinel is a high-performance reverse proxy built on Cloudflare Pingora. It provides explicit limits, predictable behavior, and production-grade defaults for environments where operators need to sleep.

Performance: Lowest p99 latency in benchmarks against Envoy, HAProxy, Nginx, and Caddy. 1M-request soak tests with 99.95% success rate and zero memory leaks. Pure Rust WAF engine processes clean traffic at 912K req/s — 30x faster than the C++ ModSecurity reference.

Status

Production-ready core (proxy, routing, TLS, caching, load balancing). Agents are individually versioned — WAF, Auth, and AI Gateway are stable; others are beta or alpha. See zentinelproxy.io/agents for per-agent status.

Request Flow

┌────────┐                                       ┌──────────┐
   │ Client │                                       │ Upstream │
   └────┬───┘                                       └─────▲────┘
        │                                                 │
        ▼                                                 │
   ╔═══════════ Zentinel (core, single binary) ══════════╤════╗
   ║                                                     │    ║
   ║  Listener ─▶ Routing ─▶ Filter chain ─▶ Forward ────┘    ║
   ║  TLS, H2     priority   rate-limit,     LB,              ║
   ║              + LRU      cache, hooks    retries          ║
   ║                              │                           ║
   ╚══════════════════════════════╪═══════════════════════════╝
                                  │ UDS / gRPC (v2 agent protocol)
                                  ▼
          ╔═══════ External agents (separate processes) ═══════╗
          ║   WAF · Auth · Rate-limit · …                      ║
          ║   crash-isolated, any language                     ║
          ╚════════════════════════════════════════════════════╝

Response retraces the filter chain back to the Client. Access logs and metrics emit at completion.

The dataplane runs as a single binary. Security and policy logic that is parsing-heavy or operationally risky lives in external agents behind UDS or gRPC, so a buggy agent cannot take the proxy down with it. See the Manifesto for the reasoning, and crates/proxy/docs/architecture.md for the per-phase details.

Quick Start

# Install (binary only)
curl -fsSL https://get.zentinelproxy.io | sh
Install and start as a systemd service (Linux, root or sudo)
curl -fsSL https://get.zentinelproxy.io | sh -s -- --enable-service
Or via Cargo
cargo install zentinel-proxy
Or via Docker
docker run -v $(pwd)/zentinel.kdl:/etc/zentinel/zentinel.kdl \
  ghcr.io/zentinelproxy/zentinel --config /etc/zentinel/zentinel.kdl

On systemd hosts the install script also drops /etc/systemd/system/zentinel.service, a sysusers snippet, and a starter config at /etc/zentinel/zentinel.kdl. Service enable and start are opt-in via --enable-service. See crates/proxy/docs/deployment.md.

Save this as zentinel.kdl — it proxies localhost:8080 to a backend on port 8081:

system {
    worker-threads 0  // auto-detect CPU cores
}
listeners {     listener "http" {         address "0.0.0.0:8080"         protocol "http"     } }
routes {     route "default" {         matches {             path-prefix "/"         }         upstream "backend"     } }
upstreams {     upstream "backend" {         target "127.0.0.1:8081"     } }

# Run
zentinel --config zentinel.kdl
Validate config without starting
zentinel test --config zentinel.kdl

Proxying to an HTTPS backend? Add a tls block to the upstream:

upstreams {
    upstream "backend" {
        target "api.example.com:443"
        tls {
            sni "api.example.com"
        }
    }
}

Without the tls block, Zentinel connects with plaintext HTTP regardless of the port.

More examples: config/examples/ covers API gateways, load balancing, WebSocket, caching, inference routing, and more. Or use the config builder to generate a config interactively.

Features

| Feature | Description | |---------|-------------| | Service Types | Web, API, Static, Builtin, and Inference (LLM/AI) | | Load Balancing | 14 algorithms: round-robin, weighted, least connections, Maglev, Peak EWMA, and more | | Security | TLS/mTLS, rate limiting, GeoIP filtering, WAF, zip bomb protection | | Agent Protocol | External agents for WAF, auth, and custom logic — crash-isolated, any language | | HTTP Caching | Pingora-based response caching with stampede prevention and LRU eviction (memory, disk, or hybrid backends) | | WebSocket Proxying | RFC 6455 compliant with per-frame agent inspection and session affinity | | Observability | Prometheus metrics, structured logging, OpenTelemetry tracing | | Hot Reload | Zero-downtime config updates via SIGHUP with validation and atomic swap (routes, upstreams, agents; listener changes require a restart) |

See the full feature breakdown at zentinelproxy.io/features.

Use Cases

• Reverse Proxy — TLS termination, static file serving, compression, and security headers for web applications
• API Gateway — Versioned routing, JWT/API key auth, per-client rate limiting, and JSON error responses
• Load Balancer — Weighted traffic distribution, health checks, circuit breakers, and blue-green/canary deployments
• Inference Gateway — Token-based rate limiting, model routing with glob patterns (gpt-4, claude-), prompt injection detection, and PII filtering for OpenAI, Anthropic, and generic LLM providers
• WebSocket Gateway — Persistent connection proxying with frame inspection, message rate limiting, and session affinity
• Security Gateway — WAF, GeoIP filtering, mTLS, and composable agent pipelines for custom security logic

Why Zentinel

Modern proxies accumulate hidden behavior, unbounded complexity, and operational risk that surfaces under stress. Zentinel takes a different approach:

• Bounded resources — Memory limits, queue depths, deterministic timeouts. No surprise behavior.
• Explicit failure modes — Fail-open or fail-closed per route, never ambiguous.
• External extensibility — Security logic lives in agents, not the core. Small, stable dataplane.
• Observable by default — Every decision is logged and metered. Features ship only when bounded, observed, and tested.

Agents

Zentinel's security and extensibility lives in agents — external processes that hook into every request phase. Agents are crash-isolated from the proxy, independently deployable, and can be written in any language.

Agent SDKs: Rust · Go · Python · TypeScript · Elixir · Kotlin · Haskell

| Agent | Description | |-------|-------------| | WAF | Pure Rust WAF — 200+ detection rules, ML-powered anomaly scoring, zero C dependencies | | AI Gateway | Prompt injection detection, jailbreak prevention, PII filtering for LLM APIs | | Policy | Multi-engine policy evaluation (Rego/OPA and Cedar) — written in Haskell | | Auth | JWT, OIDC, SAML, mTLS, API keys with Cedar-based fine-grained authorization | | Chaos | Latency injection, error simulation, connection resets with safety guardrails | | Lua | Sandboxed Lua scripting with VM pooling, hot-reload, and resource limits | | ZentinelSec | Pure Rust ModSecurity — OWASP CRS-compatible SecLang parser, zero C dependencies | | WebSocket Inspector | Content filtering, JSON/MessagePack validation, and rate limiting for WebSocket frames | | MQTT Gateway | IoT protocol security with topic ACLs, auth, and payload inspection |

Browse all 25+ agents at zentinelproxy.io/agents.

Control Plane

zentinel-control-plane — Fleet management for Zentinel proxies, built with Elixir/Phoenix. Centralized configuration, rolling deploys, and real-time observability across your Zentinel instances.

Contributing

See CONTRIBUTING.md for guidelines.

Using Claude Code? See .claude/CLAUDE.md for project context, architecture, and coding rules.

Community

• 📖 Documentation — Guides, reference, and examples
• 🎮 Playground — Try the routing engine in your browser (WASM)
• 📊 Benchmarks — Performance, soak testing, and Envoy comparison
• 💬 Discussions — Questions, ideas, show & tell
• 🐛 Issues — Bug reports and feature requests

License

Apache 2.0 — See LICENSE.
