pixelsort

What is Pixel Sorting?

Have a look at this post or /r/pixelsorting

Dependencies

Should work in both Python 2 and 3, but Python 3 is recommended.

Usage

From the command line:

pip install pixelsort
python3 -m pixelsort %PathToImage% [options]

Tip: To replicate Kim Asendorf's original processing script, first sort vertically and then horizontally in threshold (default) mode:

python3 -m pixelsort %PathToImage% -a 90
python3 -m pixelsort %PathToSortedImage%

As a package:

>>> from pixelsort import pixelsort
>>> from PIL import Image
>>> a = Image.open("examples/image.jpg")
>>> a
<PIL.JpegImagePlugin.JpegImageFile image mode=RGB size=576x324 at 0x7F8F6A2AC208>
>>> pixelsort(a)
<PIL.Image.Image image mode=RGBA size=576x324 at 0x7F8F66AA57B8>

Parameters:

Parameter | Flag | Description ------------------------|-------|------------ Interval function | -i | Controls how the intervals used for sorting are defined. See below for more details and examples. Threshold by default. Output path | -o | Path of output file. Uses the current time for the file name by default. Randomness | -r | What percentage of intervals not to sort. 0 by default. Threshold (lower) | -t | How dark must a pixel be to be considered as a 'border' for sorting? Takes values from 0-1. 0.25 by default. Used in edges and threshold modes. Threshold (upper) | -u | How bright must a pixel be to be considered as a 'border' for sorting? Takes values from 0-1. 0.8 by default. Used in threshold mode. Char. length | -c | Characteristic length for the random width generator. Used in mode random and waves. Angle | -a | Angle at which you're pixel sorting in degrees. 0 (horizontal) by default. External interval file | -f | Image used to define intervals. Must be black and white. Sorting function | -s | Sorting function to use for sorting the pixels. Lightness by default. Mask | -m | Image used for masking parts of the image. Logging level | -l | Level of logging statements made visible. Choices include DEBUG, INFO, WARNING, ERROR, and CRITICAL. WARNING by default.

Interval Functions

Interval function | Description ------------------|------------ random | Randomly generate intervals. Distribution of widths is linear by default. Interval widths can be scaled using char_length. edges | Performs an edge detection, which is used to define intervals. Tweak threshold with threshold. threshold | Intervals defined by lightness thresholds; only pixels with a lightness between the upper and lower thresholds are sorted. waves | Intervals are waves of nearly uniform widths. Control width of waves with char_length. file | Intervals taken from another specified input image. Must be black and white, and the same size as the input image. file-edges | Intevals defined by performing edge detection on the file specified by -f. Must be the same size as the input image. none | Sort whole rows, only stopping at image borders.

Sorting Functions

Sorting function | Description ------------------|------------ lightness | Sort by the lightness of a pixel according to a HSL representation. hue | Sort by the hue of a pixel according to a HSL representation. saturation | Sort by the saturation of a pixel according to a HSL representation. intensity | Sort by the intensity of a pixel, i.e. the sum of all the RGB values. minimum | Sort on the minimum RGB value of a pixel (either the R, G or B).
