osixia/keepalived 🐳🛟🌴

[docker hub]: https://hub.docker.com/r/osixia/keepalived [github]: https://github.com/osixia/container-keepalived

[][docker hub] [][docker hub] [][github]

Production-ready Keepalived container image for VRRP high availability and VIP failover with dynamic configuration and hot reload.

• osixia/keepalived 🐳🛟🌴

⚡ Quick Start

This image requires the ipvs kernel module to be loaded on the host (modprobe ipvs). It must be run with the following Docker options:

bash
docker run --cap-add=NETADMIN --cap-add=NETRAW --cap-add=NET_BROADCAST --network=host osixia/keepalived

Using your own Keepalived configuration

This image ships with a Keepalived configuration template that can be customized using environment variables for quick bootstrapping.

You can also provide your own keepalived.conf by mounting it at the path defined by KEEPALIVED_CONF (default: /etc/keepalived/keepalived.conf):

bash
docker run --volume /data/my-keepalived.conf:/etc/keepalived/keepalived.conf osixia/keepalived

Passing command-line arguments to Keepalived

The osixia/keepalived container allows you to pass additional command-line arguments directly to the keepalived binary.

Arguments specified after -- are forwarded to the keepalived process inside the container:

bash
docker run osixia/keepalived -- --dont-release-ipvs

Debugging

To debug the container manually, you can start it with an interactive shell.

The --debug option from osixia/baseimage enables debug logging, installs debugging tools, and launches an interactive shell.

If Keepalived keeps crashing, you can add --skip-process to start the container without launching service processes.

bash
docker run -it osixia/keepalived --debug
docker run -it osixia/keepalived --skip-process --debug

You can also enable Keepalived debugging options:

bash docker run osixia/keepalived -- --log-detail --dump-conf

To see all available command-line options:

bash docker run --rm osixia/keepalived --help # osixia/baseimage options docker run --rm osixia/keepalived -x keepalived -- --help # keepalived command-line options

🔤 Environment Variables

| Variable | Description | Default | | ------------------------------- | --------------------------------------------------------------------- | --------------------------------------------------------------------------- | | KEEPALIVED_CONF | Path to the Keepalived configuration file | /etc/keepalived/keepalived.conf | | KEEPALIVEDCONFTEMPLATE | Path to the configuration template used to generate keepalived.conf | /container/services/keepalived-conf/assets/confs/keepalived.conf.template | | KEEPALIVEDCONFRELOAD_SCRIPT | Script executed when configuration changes are detected | /container/services/keepalived-conf/assets/scripts/reload.sh | | KEEPALIVED_INTERFACE | Network interface used by VRRP | eth0 | | KEEPALIVED_STATE | Initial VRRP state (MASTER or BACKUP) | BACKUP | | KEEPALIVEDROUTERID | VRRP router ID | 51 | | KEEPALIVED_PRIORITY | VRRP priority of the node | 150 | | KEEPALIVEDUNICASTPEERS | List of peer nodes used for VRRP unicast communication | 192.168.1.10 192.168.1.11 | | KEEPALIVEDVIRTUALIPS | Virtual IP addresses managed by Keepalived | 192.168.1.231 192.168.1.232 | | KEEPALIVED_PASSWORD | VRRP authentication password | d0cker | | KEEPALIVEDNOTIFYSCRIPT | Script executed when Keepalived state changes | /container/services/keepalived/assets/scripts/notify.sh |

📄 Documentation

See full documentation and complete features list on osixia/keepalived documentation.

This image is based on osixia/baseimage.

🔀 Contributing

If you find this project useful here's how you can help:

• Send a pull request with new features and bug fixes.
• Help new users with issues they may encounter.
• Support the development of this image and star [this repo][github] and the image [docker hub repository][docker hub].

🔓 License

This project is licensed under the terms of the MIT license. See LICENSE.md file for more information.
