hannoy 🗼

hannoy is a key-value backed HNSW implementation based on arroy.

Motivation

Many popular HNSW libraries are built in memory, meaning you need enough RAM to store all the vectors you're indexing. Instead, hannoy uses LMDB — a memory-mapped KV store — as a storage backend. This is more well-suited for machines running multiple programs, or cases where the dataset you're indexing won't fit in memory. LMDB also supports non-blocking concurrent reads by design, meaning its safe to query the index in multi-threaded environments.

Features

Supported metrics: euclidean, cosine, manhattan, hamming, as well as quantized counterparts.
Python bindings with maturin and pyo3
Multithreaded builds using rayon
Disk-backed storage to enable indexing datasets that won't fit in RAM using LMDB
Compressed bitmaps to store graph edges with minimal overhead, adding ~200 bytes per vector
Dynamic document insertions and deletions without full re-indexing

Missing Features

GPU-accelerated indexing

Usage

Rust 🦀

use hannoy::{distances::Cosine, Database, Reader, Result, Writer};
use heed::EnvOpenOptions;
use rand::{rngs::StdRng, SeedableRng};
fn main() -> Result<()> {     let env = unsafe {         EnvOpenOptions::new()             .map_size(1024  1024  1024) // 1GiB             .open("./")     }     .unwrap();
let mut wtxn = env.write_txn()?;     let db: Database<Cosine> = env.create_database(&mut wtxn, None)?;     let writer: Writer<Cosine> = Writer::new(db, 0, 3);
// build     writer.add_item(&mut wtxn, 0, &[1.0, 0.0, 0.0])?;     writer.add_item(&mut wtxn, 0, &[0.0, 1.0, 0.0])?;
let mut rng = StdRng::seedfromu64(42);     let mut builder = writer.builder(&mut rng);     builder.ef_construction(100).build::<16,32>(&mut wtxn)?;     wtxn.commit()?;
// search     let rtxn = env.read_txn()?;     let reader = Reader::<Cosine>::open(&rtxn, 0, db)?;
let query = vec![0.0, 1.0, 0.0];     let nns = reader.nns(1).efsearch(10).byvector(&rtxn, &query)?.into_nns();
dbg!("{:?}", &nns);     Ok(()) }

Python 🐍

import hannoy
from hannoy import Metric
import tempfile
tmp_dir = tempfile.gettempdir() db = hannoy.Database(tmp_dir, Metric.COSINE)
with db.writer(3, m=4, ef=10) as writer:     writer.add_item(0, [1.0, 0.0, 0.0])     writer.add_item(1, [0.0, 1.0, 0.0])
reader = db.reader() nns = reader.by_vec([0.0, 1.0, 0.0], n=2)
(closest, dist) = nns[0]

Alternatively, you can add many items at once from a 2d numpy array of dtype float 32:

import numpy as np
with db.writer(3, m=4, ef=10) as writer:
    writer.add_items([0, 1], np.array([[3.0, 4.0, 5.0], [6.0, 7.0, 8.0]], dtype=np.float32))

Tips and tricks

Reducing cold start latencies

Search in an hnsw always traverses from the top to bottom layers of the graph, so we know a priori some vectors will be needed. We can hint to the kernel that these vectors (and their neighbours) should be loaded into RAM using madvise to speed up search.

Doing so can reduce cold-start latencies by several milliseconds, and is configured through the HANNOYREADERPREFETCH_MEMORY environment variable.

E.g. prefetching 10MiB of vectors into RAM.

export HANNOYREADERPREFETCH_MEMORY=10485760
