xfr

A modern iperf3 alternative with a live TUI, multi-client server, MPTCP, and QUIC support. Built in Rust.

Quick Start

# Server
xfr serve
Client (in another terminal or machine)
xfr 192.168.1.1              # Basic TCP test
xfr 192.168.1.1 -b 100M      # TCP at 100 Mbps
xfr 192.168.1.1 -P 4         # 4 parallel streams
xfr 192.168.1.1 -u -b 1G     # UDP at 1 Gbps

See Installation below for setup instructions.

TUI Preview

Features

• Live TUI with real-time throughput graphs and per-stream stats
• Server dashboard - xfr serve --tui for monitoring active tests
• Multi-client server - handle multiple simultaneous tests
• TCP, UDP, QUIC, and MPTCP with configurable bitrate pacing and parallel streams
• Firewall-friendly - single-port TCP and UDP (all traffic on 5201), QUIC multiplexing, and --cport for pinning data source ports
• Bidirectional testing - measure upload and download simultaneously
• Multiple output formats - plain text, JSON, JSON streaming, CSV
• Result comparison - xfr diff to detect performance regressions
• LAN discovery - find xfr servers with mDNS (xfr discover)
• Prometheus metrics - export stats for monitoring dashboards
• Config file - save defaults in ~/.config/xfr/config.toml
• Environment variables - XFRPORT, XFRDURATION overrides

vs iperf3

| Feature | iperf3 | xfr | |---------|--------|-----| | Live TUI | No | Yes (client & server) | | Multi-client server | No | Yes | | MPTCP | No | Yes (auto on server, --mptcp on client, Linux 5.6+) | | Firewall-friendly | --cport (TCP/UDP) | Single-port TCP & UDP + --cport | | Output formats | Text/JSON | Text/JSON/CSV | | Prometheus metrics | No | Yes (optional feature) | | Compare runs | No | xfr diff | | LAN discovery | No | xfr discover | | Config file | No | Yes |

Real-World Use Cases

VPN Tunnel Testing

Measure actual throughput through your VPN:

# On VPN server
xfr serve
From client, through VPN
xfr 10.8.0.1 -t 30s

UDP Congestion Detection

Test UDP at your expected rate to detect packet loss:

xfr <host> -u -b 500M -t 60s    # Watch for loss percentage in TUI

Path MTU Discovery

Find the largest UDP payload that survives the path — per direction, with the don't-fragment flag set so middleboxes can't hide the limit by fragmenting (useful for NFS-over-UDP and VPN/tunnel tuning):

xfr <host> --probe-mtu

Before/After Comparison

Quantify the impact of network changes:

xfr <host> --json -o before.json
... make changes ...
xfr <host> --json -o after.json
xfr diff before.json after.json --threshold 5

Multi-Stream for Bonded Connections

Test aggregate bandwidth across bonded/LACP interfaces:

xfr <host> -P 8 -t 30s          # 8 streams to utilize all links

Prometheus Monitoring

Continuous performance monitoring:

xfr serve --prometheus 9090 --push-gateway http://pushgateway:9091
Scrape metrics or view in Grafana

Installation

From crates.io (Recommended)

Requires Rust 1.88+:

# Install Rust (if not already installed)
curl --proto '=https' --tlsv1.2 -sSf https://sh.rustup.rs | sh
source ~/.cargo/env
Install xfr
cargo install xfr

Homebrew (macOS/Linux)

brew install lance0/tap/xfr

Docker (GHCR)

Multi-arch image (amd64/arm64), handy for running a server:

docker run --rm -p 5201:5201 -p 5201:5201/udp ghcr.io/lance0/xfr:latest serve

Pre-built Binaries

Download from GitHub Releases:

| Platform | Target | |----------|--------| | Linux x8664 | xfr-x8664-unknown-linux-musl.tar.gz | | Linux ARM64 | xfr-aarch64-unknown-linux-gnu.tar.gz (or -musl for fully static) | | macOS Apple Silicon | xfr-aarch64-apple-darwin.tar.gz | | macOS Intel | Use cargo install xfr | | Android (Termux) | xfr-aarch64-linux-android.tar.gz | | Windows | Use WSL2 (native support is experimental) |

# Example: Linux x86_64
curl -LO https://github.com/lance0/xfr/releases/latest/download/xfr-x86_64-unknown-linux-musl.tar.gz
tar xzf xfr-*.tar.gz && sudo mv xfr /usr/local/bin/

eget

eget lance0/xfr

Arch Linux (AUR)

yay -S xfr-bin

From Source

git clone https://github.com/lance0/xfr
cd xfr && cargo build --release
sudo cp target/release/xfr /usr/local/bin/

Quick Install Script

Note: Review scripts before piping to sh. See the install script source.

curl -fsSL https://raw.githubusercontent.com/lance0/xfr/master/install.sh | sh

Termux (Android)

Download the aarch64-linux-android binary from releases, or build from source:

pkg install rust
cargo install xfr

Nix

nix run github:lance0/xfr          # Run without installing
nix profile install github:lance0/xfr  # Install to profile

Or add to your flake inputs:

inputs.xfr.url = "github:lance0/xfr";

A dev shell is also available via nix develop.

NetBSD

Available via pkgsrc:

pkgin install xfr

Optional Features

| Feature | Default | Description | |---------|---------|-------------| | discovery | Yes | mDNS LAN discovery (xfr discover) | | prometheus | No | Prometheus metrics endpoint and Push Gateway support |

cargo install xfr --features prometheus    # Prometheus support
cargo install xfr --all-features           # All features

Shell Completions

# Bash
xfr --completions bash > ~/.local/share/bash-completion/completions/xfr
Zsh (add ~/.zfunc to fpath in .zshrc first)
xfr --completions zsh > ~/.zfunc/_xfr
Fish
xfr --completions fish > ~/.config/fish/completions/xfr.fish
PowerShell (add to $PROFILE)
xfr --completions powershell >> $PROFILE
Elvish
xfr --completions elvish > ~/.elvish/lib/xfr.elv

Usage

Server

xfr serve                    # Listen on port 5201
xfr serve -p 9000            # Custom port
xfr serve --tui              # Live dashboard showing active tests
xfr serve --one-off          # Exit after one test
xfr serve --max-duration 60s # Limit test duration
xfr serve --push-gateway http://pushgateway:9091  # Push metrics on test complete
xfr serve --psk mysecret     # Require PSK authentication
xfr serve --rate-limit 2     # Max 2 concurrent tests per IP
xfr serve --allow 192.168.0.0/16 --deny 0.0.0.0/0  # IP ACL

Client

xfr 192.168.1.1              # TCP test, 10s, single stream
xfr 192.168.1.1 -t 30s       # 30 second test
xfr 192.168.1.1 -P 4         # 4 parallel streams
xfr 192.168.1.1 -R           # Reverse (download test)
xfr 192.168.1.1 --bidir      # Bidirectional
xfr 192.168.1.1 -6           # Force IPv6 only
xfr ::1 -6                   # IPv6 localhost

UDP Mode

xfr 192.168.1.1 -u           # UDP mode
xfr 192.168.1.1 -u -b 1G     # UDP at 1 Gbps
xfr 192.168.1.1 -u -b 100M   # UDP at 100 Mbps

QUIC Mode

xfr 192.168.1.1 --quic       # QUIC transport (encrypted)
xfr 192.168.1.1 --quic -P 4  # QUIC with 4 parallel streams
xfr 192.168.1.1 --quic -R    # QUIC download test

QUIC provides built-in TLS 1.3 encryption with stream multiplexing over a single connection.

Security Note: QUIC encrypts traffic but does not verify server identity by default. For authenticated connections, use --psk on both client and server to prevent MITM attacks.

MPTCP Mode

xfr 192.168.1.1 --mptcp       # MPTCP (Multi-Path TCP, Linux 5.6+)
xfr 192.168.1.1 --mptcp -P 4  # MPTCP with 4 parallel streams
xfr 192.168.1.1 --mptcp -R    # MPTCP download test

MPTCP enables a single connection to use multiple network paths simultaneously (e.g., WiFi + Ethernet). The server automatically creates MPTCP listeners — no flag needed on the server side. All TCP features (nodelay, congestion control, window size, bidir, multi-stream) work transparently with MPTCP.

Output Formats

xfr <host> --json              # JSON summary
xfr <host> --json-stream       # JSON per interval (for scripting)
xfr <host> --csv               # CSV output
xfr <host> -q                  # Quiet mode (summary only)
xfr <host> -o results.json     # Save to file
xfr <host> --no-tui            # Plain text, no TUI
xfr <host> --timestamp-format iso8601  # ISO 8601 timestamps

Note: Log messages go to stderr, allowing clean JSON/CSV piping: xfr <host> --json 2>/dev/null

Interval Control

xfr <host> -i 2                # Report every 2 seconds
xfr <host> --omit 3            # Skip first 3s of intervals (TCP ramp-up)

Compare Results

xfr diff baseline.json current.json
xfr diff baseline.json current.json --threshold 5

Discovery

xfr discover                 # Find xfr servers on LAN
xfr discover --timeout 10s   # Extended search

Keybindings (Client TUI)

| Key | Action | |-----|--------| | q | Quit (cancels test) | | p | Pause/Resume test traffic | | s | Settings modal | | t | Cycle color theme | | d | Toggle per-stream view | | ? / F1 | Help | | j | Print JSON result | | u | Dismiss update notification |

Keybindings (Server TUI)

| Key | Action | |-----|--------| | q | Quit server | | ? / F1 | Help | | Esc | Close help |

Themes

xfr includes 11 built-in color themes. Select with --theme or press t during a test:

xfr <host> --theme dracula     # Dark purple theme
xfr <host> --theme matrix      # Green on black hacker style
xfr <host> --theme catppuccin  # Soothing pastels
xfr <host> --theme nord        # Arctic blue tones

Available themes: default, kawaii, cyber, dracula, monochrome, matrix, nord, gruvbox, catppuccin, tokyo_night, solarized

Your theme preference is auto-saved to ~/.config/xfr/prefs.toml.

Configuration

xfr reads defaults from:

• Linux/macOS: ~/.config/xfr/config.toml
• Windows: %APPDATA%\xfr\config.toml

[client] duration_secs = 10 parallel_streams = 1 tcp_nodelay = false windowsize = "1M"           # TCP/UDP socket buffer size (SOSNDBUF/SO_RCVBUF), e.g. "512K", "2M"
bitrate = "100M"            # target bitrate; accepts the same units as --bitrate

congestion = "bbr"          # TCP congestion-control algorithm

dscp = "EF"                 # DSCP name or raw TOS byte (0-255)
 interval_secs = 1.0           # report interval; default is 1.0 seconds json_output = false no_tui = false theme = "default"            # or dracula, catppuccin, nord, matrix, etc. timestamp_format = "relative" # or "iso8601", "unix" address_family = "dual"      # "ipv4", "ipv6", or "dual" omit_secs = 0                # omit first N seconds (TCP ramp-up)
bind = "192.168.1.100"      # local address, optionally with :port

cport = 5202                # client source port for firewall traversal
 psk = "my-secret-key" log_file = "~/.config/xfr/xfr.log" log_level = "info"

[server] port = 5201 one_off = false no_mdns = false address_family = "dual"      # "ipv4", "ipv6", or "dual" psk = "my-secret-key" rate_limit = 5 ratelimitwindow = 60 allow = ["192.168.0.0/16", "10.0.0.0/8"] deny = [] acl_file = "/path/to/acl.txt" push_gateway = "http://pushgateway:9091" log_file = "~/.config/xfr/xfr-server.log" log_level = "info"

The value-taking transport and output settings under [client] are defaults: an explicit CLI value takes precedence. This includes omitsecs and intervalsecs, so --omit 0 and --interval 1.0 override the config file. bitrate accepts the same 100M/1G syntax as --bitrate; dscp accepts the same DSCP names and numeric values as --dscp.

Environment variables override config file:

export XFR_PORT=9000
export XFR_DURATION=30s

Prometheus Metrics

Enable with --features prometheus:

xfr serve --prometheus 9090

Metrics available at http://localhost:9090/metrics:

• xfrbytestotal - Total bytes transferred
• xfrthroughputmbps - Current throughput
• xfractivetests - Number of active tests
• xfrretransmitstotal - TCP retransmissions

See examples/grafana-dashboard.json for a sample Grafana dashboard.

CLI Reference

| Flag | Short | Default | Description | |------|-------|---------|-------------| | --port | -p | 5201 | Server/client port | | --time | -t | 10s | Test duration (use 0 for infinite) | | --udp | -u | false | UDP mode | | --quic | -Q | false | QUIC mode (encrypted, multiplexed streams) | | --bitrate | -b | unlimited | Target bitrate for TCP and UDP (e.g., 1G, 100M). 0 = unlimited. Global across all streams | | --parallel | -P | 1 | Parallel streams | | --reverse | -R | false | Reverse direction (download) | | --bidir | | false | Bidirectional test | | --ipv4 | -4 | false | Force IPv4 only | | --ipv6 | -6 | false | Force IPv6 only | | --bind | | none | Local address to bind (e.g., 192.168.1.100) | | --cport | | none | Client source port for firewall traversal (UDP/QUIC/TCP data streams) | | --dscp | | none | DSCP/TOS marking for TCP/UDP QoS testing (0-255 or name: EF, AF11, CS1, etc.) | | --mptcp | | false | MPTCP mode (client-only, Linux 5.6+; server auto-enables) | | --random | | true | Use random payload data for client-sent TCP/UDP traffic (default) | | --zeros | | false | Use zero-filled payload data (client-sent traffic only) | | --zerocopy | -Z | true (TCP) | Zero-copy TCP sends via sendfile(2), like iperf3 -Z (Linux; lowers sender CPU overhead). On by default; explicit -Z warns when zero-copy can't take effect | | --no-zerocopy | | false | Disable zero-copy TCP sends (use regular buffered writes) | | --probe-mtu | | false | Probe the path MTU per direction instead of running a throughput test (UDP + DF bit; needs server ≥ this version) | | --connect-timeout | | none | Fail if the control connection takes longer than this (e.g. 5s); without it, dead servers are bounded only by OS defaults | | --json | | false | JSON output | | --json-stream | | false | JSON per interval | | --csv | | false | CSV output | | --quiet | -q | false | Summary only | | --interval | -i | 1.0 | Report interval (seconds) | | --omit | | 0 | Omit first N seconds | | --output | -o | stdout | Output file | | --no-tui | | false | Disable TUI | | --no-update-check | | false | Disable the background update check (also honors DONOTTRACK / XFRNOUPDATE_CHECK) | | --theme | | default | Color theme (dracula, nord, matrix, etc.) | | --tcp-nodelay | | false | Disable Nagle algorithm | | --window | -w | OS default | Socket buffer size for TCP and UDP (SOSNDBUF/SORCVBUF on both ends); when unset, TCP autotunes and UDP uses the kernel default | | --congestion | | OS default | TCP congestion control algorithm (e.g. cubic, bbr, reno) | | --timestamp-format | | relative | Timestamp format (relative, iso8601, unix) | | --log-file | | none | Log file path (e.g., ~/.config/xfr/xfr.log) | | --log-level | | info | Log level (error, warn, info, debug, trace) | | --push-gateway | | none | Prometheus Push Gateway URL (server) | | --prometheus | | none | Prometheus metrics port (server, requires feature) | | --psk | | none | Pre-shared key for authentication | | --psk-file | | none | Read PSK from file | | --rate-limit | | none | Max concurrent tests per IP (server) | | --rate-limit-window | | 60s | Rate limit time window (server) | | --completions | | none | Generate shell completions (bash, zsh, fish, powershell, elvish) | | --allow | | none | Allow IP/subnet, repeatable (server) | | --deny | | none | Deny IP/subnet, repeatable (server) | | --acl-file | | none | ACL rules file (server) | | --max-duration | | none | Maximum test duration, server-side limit (server) | | --tui | | false | Enable live dashboard (server) | | --one-off | | false | Exit after one test (server, works with TCP and QUIC) | | --no-mdns | | false | Disable mDNS service registration (server) |

TCP and UDP tests use random payloads by default to avoid inflated results on WAN-optimized or compressing paths. --random and --zeros control client-sent traffic. Server-sent TCP/UDP traffic also defaults to random, but payload mode is not negotiated over the wire.

--dscp applies to TCP and UDP sockets on both ends when relevant, including server-sent download and bidirectional traffic. QUIC ignores it because the underlying socket is managed by Quinn, and non-Unix platforms currently warn instead of applying socket marking.

Security Considerations

Transport Encryption

| Mode | Encryption | Certificate Verification | |------|------------|-------------------------| | TCP | None | N/A | | UDP | None | N/A | | QUIC | TLS 1.3 | Disabled by default |

QUIC mode (-Q/--quic) provides TLS 1.3 encryption but does not verify server certificates, making it vulnerable to MITM attacks without additional authentication. Always use --psk with QUIC on untrusted networks. Alternatively, use a VPN or SSH tunnel.

Authentication

PSK authentication (--psk) verifies client identity but does not encrypt TCP/UDP traffic. For encrypted + authenticated connections, use QUIC with PSK:

# Server
xfr serve --psk "secretkey"
Client (encrypted + authenticated)
xfr <host> -Q --psk "secretkey"

Security note: --psk and the XFR_PSK environment variable expose the

key through process metadata such as ps, shell history, and

/proc/<pid>/environ. For production deployments, store the key in a file

readable only by the owner and use --psk-file instead.

Network Considerations

• Single-port TCP: TCP uses single-port mode by default -- control and data connections share port 5201. Data connections are validated against the control connection's IP address, preventing unauthorized access.
• UDP on untrusted networks: UDP mode may be susceptible to reflection attacks from spoofed source addresses. Use TCP or QUIC on public networks.
• Rate limiting: Use --rate-limit on public servers to prevent abuse.
• ACLs: Use --allow/--deny to restrict client access.

DoS Protections

• Slow-loris resistance: New connections must send their first message within 5 seconds, preventing slow-loris attacks from blocking the accept loop.
• DataHello flood protection: DataHello messages for unknown test IDs are rejected immediately without allocating resources.
• Bounded reads: All control messages are limited to 8KB, preventing memory exhaustion from oversized messages.
• Capability negotiation: Client and server exchange capabilities during the Hello handshake (protocol version 1.1), enabling safe feature evolution.
• Concurrent connection limits: Server limits concurrent handlers (default 100) to prevent connection floods.

Server Resource Usage

Each TCP stream allocates a 128 KB application read/write buffer. Kernel socket buffers are managed by TCP autotuning unless the client passes -w/--window, in which case the requested size is applied via SOSNDBUF/SORCVBUF on both ends. Memory usage scales with concurrent clients:

| Streams per client | App buffer per client | 10 clients (app buffers) | |-------------------|-----------------------|--------------------------| | 1 (-P 1) | 128 KB | 1.3 MB | | 8 (-P 8) | 1 MB | 10 MB | | 128 (-P 128) | 16 MB | 160 MB |

On top of that, the kernel holds autotuned socket buffers (typically a few hundred KB per stream, capped by net.ipv4.tcprmem[2]/tcpwmem[2]). When a client passes -w N, add roughly N bytes per stream on each side. The server limits concurrent handlers (default 100) to prevent resource exhaustion. Use --rate-limit to restrict tests per IP.

Platform Support

| Platform | Status | |----------|--------| | Linux x86_64/ARM64 | Full support, pre-built binaries | | macOS Apple Silicon | Full support, pre-built binaries | | macOS Intel | Full support, build from crate: cargo install xfr | | Android (Termux) | Full support, pre-built binaries | | NetBSD | Full support, via pkgsrc: pkgin install xfr | | Windows | Experimental (WSL2 recommended). Native builds work but lack TCP_INFO metrics. |

Troubleshooting

Permission denied on port 5201

Use a port above 1024 or run with elevated privileges:

xfr serve -p 9000

Connection refused

Ensure the server is running and the port is not blocked by a firewall. TCP, UDP, and QUIC all run entirely on port 5201 (or your custom port) when both ends are current -- no server-side ephemeral data ports are needed (UDP single-port requires both ends ≥ v0.9.18; older pairings fall back to ephemeral server ports automatically). For strict egress policies or ECMP testing, use --cport to pin client source ports.

Low throughput

• Try multiple parallel streams: -P 4
• Disable Nagle's algorithm: --tcp-nodelay
• Increase TCP socket buffer: --window 4M
• On CPU-bound senders (embedded routers, SBCs), the per-write userspace copy is skipped by default via sendfile(2) (TCP, Linux). This applies to client sends, and to server sends in -R/--bidir when the server supports it; pass -Z to get a warning when zero-copy can't take effect, or --no-zerocopy to disable it

UDP packet loss

• Reduce bitrate: -b 500M
• Check for network congestion or firewall issues
• If the receiver may be CPU-bound or its kernel UDP buffer is small, increase --window (e.g. -w 16M) — -w applies to UDP SOSNDBUF/SORCVBUF and propagates to the server, helping high-rate flows avoid kernel tail-drops that hide as live 0.0% loss

Documentation

• Comparison with iperf3 - Feature matrix and migration guide
• Scripting & CI/CD - Automation, Docker, Prometheus
• Features Reference - Detailed feature documentation
• Architecture - For contributors
• Changelog - Release history
• Known Issues - Edge cases and limitations
• Roadmap - Planned features
• Contributing - Development guidelines

See Also

• Terminal Trove - xfr listing and discovery
• AUR - Arch Linux package (community-maintained)
• pkgsrc - NetBSD package (community-maintained)

Acknowledgments

Special thanks to Matthieu Baerts (matttbe), Linux kernel MPTCP co-maintainer, for extensive testing, detailed bug reports with packet traces, and feature suggestions including MPTCP support, kernel TCP pacing, zero-copy IO, and high stream-count hardening. xfr is significantly better because of his contributions.

License

Licensed under either of Apache License, Version 2.0 or MIT license at your option.
