Dymension Hub

Overview

Welcome to the Dymension Hub, the Settlement Layer of the Dymension protocol.

This guide will walk you through the steps required to set up and run a Dymension Hub full node.

Table of Contents

• Dymension Hub

- Overview - Table of Contents - Prerequisites - Installation - Initializing dymd - Running the Chain - Bootstrapping liquidity pools - Adding incentives - Creating incentives streams - Locking tokens - Checking rewards - Updating a community-driven distribution - Debugging Container - Developer - Setup push hooks

Prerequisites

• Go (v1.18 or above)

Installation

Clone dymension:

git clone https://github.com/dymensionxyz/dymension.git
cd dymension
make install

Check that the dymd binaries have been successfully installed:

dymd version

If the dymd command is not found an error message is returned, confirm that your GOPATH is correctly configured by running the following command:

export PATH=$PATH:$(go env GOPATH)/bin

Initializing dymd

• Using the setup script:

This method is preferred as it is preconfigured to support running rollapps locally

bash scripts/setup_local.sh

• Manually:

First, set the following environment variables:

export CHAINID="dymension100-1"
  export KEY_NAME="hub-user"
  export M

Second, create genesis and init dymension chain:

dymd init "$MONIKERNAME" --chain-id "$CHAINID"

Third, set parameters to ensure denom is udym:

bash scripts/set_params.sh

Then, add genesis account and provide token to the account:

dymd keys add "$KEY_NAME" --keyring-backend test
  dymd add-genesis-account "$(dymd keys show "$KEY_NAME" -a --keyring-backend test)" 1000dym
  dymd gentx "$KEYNAME" 670dym --chain-id "$CHAINID" --keyring-backend test
  dymd collect-gentxs

Running the Chain

Now start the chain!

dymd start

You should have a running local node!

Bootstrapping liquidity pools

To bootstrap the GAMM module with pools:

sh scripts/pools/pools_bootstrap.sh

Adding incentives

Creating incentives streams

After creating the pools above, we create 3 incentive streams through gov:

sh scripts/incentives/fund_incentives.sh

Wait for the gov proposal to pass, and validate with:

dymd q streamer streams

The last stream is community-driven and governed by x/sponsorship.

Locking tokens

To get incentives, we need to lock the LP tokens:

sh scripts/incentives/lockup_bootstrap.sh

validate with:

dymd q lockup module-balance

Checking rewards

Every minute a share of the rewards will be distributed!

validate with:

dymd q incentives active-gauges
alternatively, watch the output - you will see the "amount" change every minute
 watch -n1 -d "dymd q incentives active-gauges --output json | jq '.data[] | { "id": .id, "coins": .coins } '"

Updating a community-driven distribution

The following script casts two votes for a community-driven distribution.

sh scripts/incentives/sponsorship_vote.sh

This will change the corresponding stream distribution at the end of the current epoch.

dymd q streamer streams

The community-driven distribution may be queried with:

dymd q sponsorship distribution

Debugging Container

Pre-requisite: Install Docker Install VSCode Install VSCode Go extension Install Delve

To debug, you can use the following command to run the debug container:

make docker-run-debug

Then you can run the debugger with the following config for launch.json in VSCode:

{
    "version": "0.2.0",
    "configurations": [
        {
            "name": "Dymension Debug Container",
            "type": "go",
            "request": "attach",
            "mode": "remote",
            "port": 4000,
            "host": "127.0.0.1",
            "debugAdapter": "legacy" // To be removed in the future after https://github.com/golang/vscode-go/issues/3096 is fixed
        }
    ]
}

After that, you can run the debugger and set breakpoints in the code.

Example:

Add breakpoint to ctx in x/eibc/keeper/grpc_query.go :

func (q Querier) Params(goCtx context.Context, req types.QueryParamsRequest) (types.QueryParamsResponse, error) {
	if req == nil {
		return nil, status.Error(codes.InvalidArgument, "invalid request")
	}
	ctx := sdk.UnwrapSDKContext(goCtx)
return &types.QueryParamsResponse{Params: q.GetParams(ctx)}, nil }

Open your browser and go to http://localhost:1318/dymensionxyz/dymension/eibc/params and you will see debugger stop and print the value at the breakpoint.

Developer

For support, join our Discord community and find us in the Developer section. See Contribution guidelines.

Setup push hooks

To setup push hooks, run the following command:

./scripts/setup-git-hooks.sh
