Kube-Beacon Project

Scan your kubernetes runtime !!

Kube-Beacon is an open source audit scanner who perform audit check on a deployed kubernetes cluster and output a security report.

The audit tests are the full implementation of CIS Kubernetes Benchmark specification

NEW !! audit result now can be leveraged as webhook via user plugin(using go plugin)

Audit checks are performed on master and worker nodes and the output audit report include :

• root cause of the security issue
• proposed remediation for security issue

kubernetes cluster audit scan output:

• Installation
• Quick Start
• Kube-beacon as Docker
• Kube-beacon as pod in k8s
• User Plugin Usage
• Next steps

Installation

git clone https://github.com/chen-keinan/kube-beacon
cd kube-beacon
make build

• Note: kube-beacon require root user to be executed

Quick Start

Execute kube-eacon without any flags , execute all tests

./kube-beacon

Execute kube-beacon with flags , execute test on demand

Usage: kube-Beacon [--version] [--help] <command> [<args>]
Available commands are:   -r , --report :  run audit tests and generate failure report   -i , --include: execute only specific audit test,   example -i=1.2.3,1.4.5   -e , --exclude: ignore specific audit tests,  example -e=1.2.3,1.4.5   -n , --node:    execute audit tests on specific node,   example -n=master,-n=worker   -s , --spec:    execute specific audit tests spec,   example -s=gke, default=k8s   -v , --version:  execute specific audit tests spec version,    example -v=1.1.0,default=1.6.0

Execute tests and generate failure tests report

./kube-beacon -r

Kube-beacon as pod in k8s

• Execute kube beacon as a pod in k8s cluster

• Add cluster role binding with role=cluster-admin

kubectl create clusterrolebinding default-admin --clusterrole cluster-admin --serviceaccount=default:default

cd jobs

• simple k8s cluster run following job

kubectl apply -f k8s.yaml

• gke cluster run the following job

kubectl apply -f gke.yaml

• Check k8s pod status

kubectl get pods --all-namespaces
NAMESPACE     NAME                                                        READY   STATUS      RESTARTS   AGE default       kube-beacon-sc8g9                                           0/1     Completed   0          111s kube-system   event-exporter-gke-8489df9489-skcvv                         2/2     Running     0          7m24s kube-system   fluentd-gke-7d5sl                                           2/2     Running     0          7m6s kube-system   fluentd-gke-f6q5d                                           2/2     Running     0          6m59s

• Check k8s pod audit output

kubectl logs kube-beacon-sc8g9

• cleanup (remove role and delete pod)

kubectl delete clusterrolebinding default-admin

kubectl delete -f k8s.yaml

User Plugin Usage

The Kube-Beacon expose hook for user plugins Example :

• K8sBenchAuditResultHook - this hook accepts audit benchmark results as found by audit report

Compile user plugin

go build -buildmode=plugin -o=~/<plugin folder>/benchplugin.so /<plugin folder>/benchplugin.go

Copy plugin to folder (.beacon folder is created on the 1st startup)

cp /<plugin folder>/benchplugin.so ~/.beacon/plugins/compile/benchplugin.so

Note: Plugin and binary must compile with the same linux env ## Next steps

• Add support for Amazon EKS scanning
