Photomosaic Creator

Index

• Install needed packages
• Introduction
• Results
• Run the script
• How it works

- createphotomosaic - getbest - treatimages - treatallimages - createallfolder - cleanbestfolders

• Possible errors

Install needed packages

pip3 install -r requirements.txt

1. Introduction

This program allows you to create a photomosaic from a set of images.

You can use the preset sets/folders of images or you can upload your own folders to the images folder.

2. Results

https://user-images.githubusercontent.com/65092569/200093661-00c553d7-2e53-48b0-8513-beaada3676cb.mp4

3. Run the script

Call the desired functions in this part of the main.py file:

#########################################################################################
startTime = time.time()
#########################################################################################
Your calls go here
create_photomosaic(      main_image= "lion-h.jpg",      imagesfolder= "$b$all",     new_name= "photomosaic",     num_images= False,     save_fullres= False,     save_lowres= True,     save_gif= False,     savegifreversed= False,     save_vid= False,     savevidreversed= True,     save_zooms= False,     resize_main= False,     images_size= 50,     quality= 85,     maxzoomedimages= 5,     zoom_incr= 1.02,     frame_duration= 30 ) ######################################################################################### print(f'{Fore.CYAN}Done in: {round(time.time() - startTime,4)}s{Fore.RESET}') #########################################################################################

Open the terminal, go to this path and type:

python3 main.py

Then, after the script runs, the result should appear in the output folder.

4. How it works

create_photomosaic

Creates a photomosaic from a set of images

Arguments

| Argument | Description | Default | Example | Range | | -------- | ----------- | ------- | ------- | ----- | | main_image | Filename of the main image, save on the main-images folder | lion-h | elephant-h.jpg || | images_size | Size of the images to be used in the photomosaic | 50 | 100 || | imagesfolder | Folder inside the images folder to be used as a set of images | $b$all | animals || | new_name | Name of the new image and folder | photomosaic | lion || | num_images | Number of images to be used to create the photomosaic | False | 255 | [3,255] | | quality | Quality of the new images | 85 | 75 | [0,100] | | save_fullres | Save the photomosaic in the full resolution | False | True || | save_lowres | Save the photomosaic in the same resolution as the main image | True | False || | save_gif | Save the photomosaic as a GIF, created by zooming into the photomosaic | False | True || | savegifreversed | Save the photomosaic as a GIF, created by zooming out the photomosaic | False | True || | save_vid | Save the photomosaic as a vid, created by zooming into the photomosaic | True | False || | savevidreversed | Save the photomosaic as a vid, created by zooming out of the photomosaic | True | False || | save_zooms | Save zoomed images of the photomosaic | False | True || | resize_main | Resize the main image (If you have an image too big to process) | False | (720, 540) | [1,...] | | maxzoomedimages | Maximum number of images the final zoomed image will have | 10 | 5 | [1,...] | | zoom_incr | Increment of the zoom in each frame | 1.05 | 1.015 | [1,...] | | frame_duration | Duration of each frame of the GIF/video, in milliseconds | 30 | 15 | [1,...] |

Explanation

• Creates the needed folders
• If resizemain != False, resizes the mainimage to resize_main, a tuple with the width and the height.
• If num_images != False, it will obtain the best images to create the photomosaic, based on the palette of colors of the main image.
• Sorts the files in the images_folder folder
• Gets the average color of each image in the images_folder folder
• Creates a list with all the numpy arrays of the images in the imagesfolder folder, resized to imagessize
• Creates an empty numpy array (newimgarr) with the size of the main image multiplied by images_size
• For each pixel in the mainimage array, it will add to the newimg_arr the image whose average color matches best with the pixel's color
• Creates a folder to store the created images, with the name new_name
• Saves the result in the output folder with quality quality:

- If save_fullres == True, it will save the photomosaic in the full resolution - If save_lowres == True, it will save the photomosaic in the same resolution as the main image - If save_zooms == True, it will save zoomed images of the photomosaic - If save_gif == True, it will save the photomosaic as a GIF, created by zooming into the photomosaic - If savegifreversed == True, it will save the photomosaic as a GIF, created by zooming out the photomosaic - If save_vid == True or, it will save the photomosaic as a video, created by zooming into the photomosaic - If savevidreversed == True, it will save the photomosaic as a video, created by zooming out of the photomosaic

Examples

# Default
create_photomosaic(
    main_image= "lion-h.jpg",
    imagesfolder= "$b$all",
    new_name= "photomosaic",
    num_images= False,
    save_fullres= False,
    save_lowres= True,
    save_gif= False,
    savegifreversed= False,
    save_vid= False,
    savevidreversed= True,
    save_zooms= False,
    resize_main= False,
    images_size= 50,
    quality= 85,
    maxzoomedimages= 5,
    zoom_incr= 1.02,
    frame_duration= 30
)
create_photomosaic(      main_image= "elephant-h.jpg",      images_size= 50,     imagesfolder= "$banimals",     new_name= "elephant",     num_images= 255,     save_zooms= True, )
create_photomosaic(      main_image= "tiger-m.jpg",      images_size= 50,     new_name= "tiger", )

get_best

Gets the best images from the folder folder

Arguments

| Argument | Description | Default | Example | Range | | -------- | ----------- | ------- | ------- | ----- | | folder | Folder inside the images folder to be used | $all | animals || | maxavgcolor_deviation | Maximum average of the deviations from every pixel from the image's average color | 765 | 120 | [0,765] | | max_contrast | Maximum contrast between the image's top and bottom and left and right parts | 765 | 150 | [0,765] | | size | Size that the images of the new folder will have. The less size, the less it will take to create a photomosaic with these images | 1000 | 200 | [1,...] |

Explanation

• Creates a new folder inside the images folder, with the name of the folder argument preceded by $b_
• Sorts the files in the folder folder
• Gets the average color of each image in the folder folder
• Checks each image in the folder folder. If it meets the requirements (checkcontrasts(...) == True and checkcolor_deviation(...) == True), it will be added to the new folder:

Examples

# Default
get_best(
    folder= "$all",
    maxavgcolor_deviation= 765,
    max_contrast= 765,
    size= 1000
)
get_best(     folder= "animals",     maxavgcolor_deviation= 120,     max_contrast= 150,     size= 200 )

treatallimages

Arguments

| Argument | Description | Default | Example | Range | | -------- | ----------- | ------- | ------- | ----- | | size | Size that the treated images of all the folders will have | 1000 | 500 | [1,...] |

Explanation

Resizes and eliminates duplicates from every folder

Examples

# Default
treatallimages(
    size= 1000
)

createallfolder

Arguments

| Argument | Description | Default | Example | Range | | -------- | ----------- | ------- | ------- | ----- | | size | Size that the images of the new folder will have | 200 | 100 | [1,...] |

Explanation

Creates a new folder called $all inside the images folder, with all the images of the folders (not including the "best folders" (that start with $b_)) inside the images folder

Examples

# Default
createallfolder(
    size= 200
)
createallfolder(     size= 100 )

cleanbestfolders

Explanation

Deletes the best folders (the ones that start with $b_)

Examples

cleanbestfolders()

5. Possible errors

If you get the error: zsh: killed python3 main.py, it means that the program is taking too much memory.

To solve it, you can try to reduce the imagessize in createphotomosaic or the size of the mainimage.
