🎯 What is PayFlow?

PayFlow is a digital wallet system — think of it like a simplified version of Paytm, PhonePe, or Google Pay's backend.

What can users do?

• 📝 Sign up & log in securely (passwords are encrypted, sessions use JWT tokens)
• 💰 Create a wallet and add money to it
• 💸 Send money to other users instantly
• 📊 View transaction history and download wallet statements
• ⭐ Save frequent contacts as beneficiaries for quick transfers
• 🔔 Get notified automatically when a transaction happens

What makes this a real engineering project (not a tutorial)?

| Challenge | How PayFlow Solves It | |-----------|----------------------| | Two people send money from same wallet at once | Pessimistic Locking — database locks the wallet row, processes one at a time | | Network glitch causes same payment request twice | Idempotency Keys — duplicate detected, money deducted only once | | Two transfers between same wallets cause system freeze | Deadlock Prevention — wallets always locked in fixed order | | Sending email slows down the payment | Event-Driven Architecture — payment completes instantly, email sent in background via RabbitMQ | | One service goes down, others break | Microservices — each service runs independently with its own database |

---

🏗 Architecture

┌─────────────────────────────────────────────────────────────────┐
│                         API Clients                             │
│                   (Mobile App / Web App)                        │
└───────────┬──────────────────┬──────────────────┬───────────────┘
            │                  │                  │
            ▼                  ▼                  ▼
  ┌─────────────────┐ ┌──────────────────┐ ┌──────────────────┐
  │  🔐 Auth        │ │  💰 Wallet       │ │  🔔 Notification │
  │  Service        │ │  Service         │ │  Service         │
  │  (:8081)        │ │  (:8082)         │ │  (:8083)         │
  │                 │ │                  │ │                  │
  │ • Register      │ │ • Create Wallet  │ │ • Email Alerts   │
  │ • Login (JWT)   │ │ • Add Money      │ │ • Templates      │
  │ • User Profile  │ │ • Send Money     │ │ • Retry Failed   │
  │ • Role Access   │ │ • Statement      │ │ • Statistics     │
  │                 │ │ • Beneficiaries  │ │                  │
  └────────┬────────┘ └───────┬──┬───────┘ └────────▲─────────┘
           │                  │  │                   │
           │                  │  │   ┌───────────┐   │
           │                  │  └──►│ 🐰        │───┘
           │                  │      │ RabbitMQ   │
           │                  │      │ (Messages) │
           │                  │      └───────────┘
  ┌────────▼────────┐ ┌──────▼─────────┐ ┌──────────────────┐
  │  🗄️ payflow   │ │  🗄️ payflow  │ │  🗄️ payflow_    │
  │  auth (MySQL)   │ │  wallet (MySQL) │ │  notification    │
  │                 │ │                 │ │  (MySQL)         │
  └─────────────────┘ └────────────────┘ └──────────────────┘

Each service has its own database — no shared tables, no tight coupling. Services communicate through REST APIs (synchronous) and RabbitMQ (asynchronous events).

---

🛠 Tech Stack

Java 17

Spring Boot 3

MySQL 8

Docker

RabbitMQ

| Category | Technologies | |:---------|:------------| | Language | Java 17 | | Framework | Spring Boot 3.2, Spring Security, Spring Data JPA | | Authentication | JWT (JSON Web Tokens), BCrypt password hashing | | ORM & Database | Hibernate, MySQL 8 (one database per service) | | Messaging | RabbitMQ (AMQP) for async event-driven communication | | API Docs | Swagger / OpenAPI 3 (interactive API playground) | | Testing | JUnit 5, Mockito, H2 in-memory DB (60+ test cases) | | Containerization | Docker, Docker Compose (one-command startup) | | CI/CD | GitHub Actions (automated build + test on every push) |

---

✨ Features

🔐 Auth Service — User Identity & Security

| Feature | Description | |---------|-------------| | User Registration | Sign up with email, username, password (validated) | | JWT Login | Login returns a signed token — no session storage needed | | Password Security | BCrypt hashing — passwords never stored in plain text | | Role-Based Access | ADMIN and USER roles with different permissions | | Protected Routes | Profile endpoint only accessible with valid JWT |

💰 Wallet Service — Core Payment Engine

| Feature | Description | |---------|-------------| | Wallet Management | Create, view, freeze, and unfreeze wallets | | Add Money | Top-up wallet balance (like adding money to Paytm) | | Send Money | Transfer to another wallet with real-time balance update | | Pessimistic Locking | Database-level locks prevent double-spending | | Idempotent Transactions | Duplicate requests safely return same result | | Deadlock Prevention | Wallets locked in ascending ID order | | Daily Transfer Limits | Configurable limit (default: ₹1,00,000/day) | | Transaction Reversal | Reverse completed transactions (compensating transaction) | | Beneficiary Management | Save, list, and remove frequent transfer recipients | | Wallet Statements | Date-filtered history with total credits/debits summary | | BigDecimal Precision | All money calculations use BigDecimal (no rounding errors) |

🔔 Notification Service — Smart Alerts

| Feature | Description | |---------|-------------| | Event-Driven | Listens to RabbitMQ — gets triggered automatically on transactions | | Email Notifications | Sends transaction receipts and alerts | | Templates | Create reusable notification templates with {{variables}} | | Retry Mechanism | Failed notifications auto-retry (configurable max retries) | | Statistics Dashboard | Track sent, pending, and failed notification counts |

---

📡 API Endpoints

🔐 Authentication (auth-service — port 8081)

| Method | Endpoint | Description | |:------:|----------|-------------| | POST | /api/auth/register | Register a new user | | POST | /api/auth/login | Login and receive JWT token | | GET | /api/auth/profile | Get current user profile (requires JWT) |

💰 Wallets (wallet-service — port 8082)

| Method | Endpoint | Description | |:------:|----------|-------------| | POST | /api/wallets | Create a new wallet | | GET | /api/wallets/{walletId} | Get wallet details | | GET | /api/wallets/user/{userId} | Get wallet by user ID | | PUT | /api/wallets/{walletId}/freeze | Freeze a wallet | | PUT | /api/wallets/{walletId}/unfreeze | Unfreeze a wallet |

💸 Transactions (wallet-service — port 8082)

| Method | Endpoint | Description | |:------:|----------|-------------| | POST | /api/transactions/wallets/{walletId}/add-money | Add money to wallet | | POST | /api/transactions/wallets/{walletId}/send-money | Send money to another wallet | | GET | /api/transactions/{transactionId} | Get transaction details | | GET | /api/transactions/wallets/{walletId}/history | Transaction history (paginated) | | GET | /api/transactions/wallets/{walletId}/statement | Wallet statement (date range) | | POST | /api/transactions/{transactionId}/reverse | Reverse a transaction |

⭐ Beneficiaries (wallet-service — port 8082)

| Method | Endpoint | Description | |:------:|----------|-------------| | POST | /api/wallets/{walletId}/beneficiaries | Add a beneficiary | | GET | /api/wallets/{walletId}/beneficiaries | List all beneficiaries | | DELETE | /api/wallets/{walletId}/beneficiaries/{id} | Remove a beneficiary |

🔔 Notifications (notification-service — port 8083)

| Method | Endpoint | Description | |:------:|----------|-------------| | GET | /api/notifications | List all notifications | | GET | /api/notifications/{id} | Get notification details | | POST | /api/notifications/{id}/retry | Retry a failed notification | | GET | /api/notifications/stats | Notification statistics | | POST | /api/notification-templates | Create notification template | | GET | /api/notification-templates | List all templates | | PUT | /api/notification-templates/{id} | Update a template | | DELETE | /api/notification-templates/{id} | Delete a template |

---

🚀 Getting Started

Prerequisites

• ☕ Java 17+
• 📦 Maven 3.8+
• 🐳 Docker & Docker Compose

Quick Start (Docker) — One Command Setup

git clone https://github.com/Shubh2-0/PayFlow.git
cd PayFlow
docker-compose up --build

That's it! All services will be running:

| Service | URL | Swagger Docs | |---------|-----|:------------:| | 🔐 Auth Service | http://localhost:8081 | Open | | 💰 Wallet Service | http://localhost:8082 | Open | | 🔔 Notification Service | http://localhost:8083 | Open | | 🐰 RabbitMQ Dashboard | http://localhost:15672 | — |

Manual Setup (without Docker)

• Start MySQL and create databases:

CREATE DATABASE payflow_auth;
   CREATE DATABASE payflow_wallet;
   CREATE DATABASE payflow_notification;

• Start RabbitMQ on port 5672

• Run each service:

cd auth-service && mvn spring-boot:run
   cd wallet-service && mvn spring-boot:run
   cd notification-service && mvn spring-boot:run

---

📘 Usage Examples

1. Register a user:

curl -X POST http://localhost:8081/api/auth/register \   -H "Content-Type: application/json" \   -d '{     "username": "john",     "email": "john@example.com",     "password": "secret123",     "fullName": "John Doe"   }'

2. Login and get JWT token:

curl -X POST http://localhost:8081/api/auth/login \   -H "Content-Type: application/json" \   -d '{"username": "john", "password": "secret123"}'

3. Add ₹5,000 to wallet:

curl -X POST http://localhost:8082/api/transactions/wallets/1/add-money \   -H "Content-Type: application/json" \   -d '{     "amount": 5000.00,     "description": "Initial top-up",     "idempotencyKey": "topup-001"   }'

4. Send ₹1,500 to another wallet:

curl -X POST http://localhost:8082/api/transactions/wallets/1/send-money \   -H "Content-Type: application/json" \   -d '{     "receiverWalletId": 2,     "amount": 1500.00,     "description": "Payment for services",     "idempotencyKey": "txn-001"   }'

---

📁 Project Structure

PayFlow/
│
├── 🐳 docker-compose.yml          # One-command setup for all services
├── 🗄️ init-db.sql                 # Auto-creates all 3 databases
├── 📦 pom.xml                      # Parent Maven POM
│
├── 🔐 auth-service/                # Authentication & User Management
│   └── src/main/java/
│       ├── controller/             # REST API endpoints
│       ├── dto/                    # Request/Response objects
│       ├── entity/                 # User, Role (JPA entities)
│       ├── exception/              # Error handling
│       ├── repository/             # Database queries
│       ├── security/               # JWT filter, config, token service
│       └── service/                # Business logic
│
├── 💰 wallet-service/              # Core Payment Engine
│   └── src/main/java/
│       ├── controller/             # Wallet, Transaction, Beneficiary APIs
│       ├── dto/                    # 10 DTOs for all operations
│       ├── entity/                 # Wallet, Transaction, Beneficiary
│       ├── enums/                  # WalletStatus, TransactionType/Status
│       ├── event/                  # RabbitMQ event publisher
│       ├── exception/              # 6 domain-specific exceptions
│       ├── repository/             # Queries with pessimistic locking
│       └── service/                # Transaction logic, daily limits
│
├── 🔔 notification-service/        # Event-Driven Notifications
│   └── src/main/java/
│       ├── config/                 # RabbitMQ queue/exchange setup
│       ├── controller/             # Notification & Template APIs
│       ├── dto/                    # TransactionEvent, responses
│       ├── entity/                 # Notification, Template
│       ├── listener/               # RabbitMQ event consumer
│       ├── repository/             # Database queries
│       └── service/                # Email & notification logic
│
└── 🔄 .github/workflows/
    └── ci.yml                      # GitHub Actions CI pipeline

---

🧠 Design Decisions

These are the engineering choices that make PayFlow production-grade, not just another CRUD project.

1. Why Pessimistic Locking for Balance Updates?

Problem: If two requests read wallet balance (₹1000) at the same time, both deduct ₹500, and both write ₹500 — the user loses ₹500.

Solution: SELECT ... FOR UPDATE locks the wallet row. Second request waits until first completes. No money is lost.

Why not Optimistic Locking? In payments, retrying a failed transaction is risky and expensive. Better to wait 10ms for a lock than risk incorrect balances.

2. Why Idempotency Keys?

Problem: User clicks "Pay" → network timeout → user clicks again → money deducted twice.

Solution: Every transaction has a unique idempotencyKey. If the same key comes again, we return the existing result instead of creating a new transaction. This is how Stripe, Razorpay, and every production payment API works.

3. Why Ordered Locking for Deadlock Prevention?

Problem: Transfer A→B locks wallet A, then tries to lock B. Simultaneously, transfer B→A locks wallet B, then tries to lock A. Both wait forever = deadlock.

Solution: Always lock the wallet with the smaller ID first. Both transfers lock A first, then B. No circular wait = no deadlock. Ever.

4. Why Event-Driven Notifications?

Problem: Sending email inside the payment transaction — if email server is slow (3 seconds), payment is slow. If email fails, does the payment rollback?

Solution: Payment completes → event published to RabbitMQ → notification service picks it up independently. Payment is fast, email failures don't affect payments, and we can add new consumers (SMS, push notifications) without changing wallet-service.

5. Why Database Per Service?

Problem: Shared database = one service changes a table, other service breaks. Tight coupling defeats the purpose of microservices.

Solution: payflowauth, payflowwallet, payflow_notification — three separate databases. Each service owns its data. No cross-database joins.

---

🧪 Testing

60+ test cases across 12 test classes in all three services:

| Type | What it Tests | Tools | |------|--------------|-------| | Unit Tests | Service layer logic in isolation | JUnit 5, Mockito | | Controller Tests | API endpoints, request validation, error responses | @WebMvcTest, MockMvc | | Repository Tests | Database queries and JPA mappings | @DataJpaTest, H2 |

# Run all tests
cd auth-service && mvn test
cd wallet-service && mvn test
cd notification-service && mvn test

---

🔄 CI/CD

GitHub Actions automatically runs on every push:

• ☕ Sets up JDK 17 (Temurin) with Maven caching
• 🔨 Builds all three services (mvn clean verify)
• 🧪 Runs complete test suite

---

📄 License

This project is licensed under the MIT License.

---

---

👤 Author

• Shubham Bhati (Java Backend Engineer) - LinkedIn | Portfolio
