aiomql

Asynchronous MetaTrader 5 Library & Algorithmic Trading Framework

Overview

aiomql is a Python framework for building algorithmic trading bots on top of MetaTrader 5. It wraps every MT5 API call in an async-friendly interface and provides high-level abstractions for strategies, risk management, trade execution, session management, and position tracking — so you can focus on your trading logic instead of boilerplate.

Key Features

• Async-first MT5 interface — every MT5 function wrapped with asyncio.to_thread and automatic reconnection
• Full synchronous API — every async class has a sync counterpart for scripts and notebooks
• Bot orchestrator — run multiple strategies on multiple instruments concurrently via thread-pool executors
• Strategy base class — define trade(), set parameters, and let the framework handle the execution loop
• Session management — restrict trading to specific time windows (London, New York, Tokyo, etc.)
• Risk & money management — built-in RAM (Risk Assessment & Money) manager
• Trade recording — persist results to CSV, JSON, or SQLite
• Position tracking — monitor open positions with trailing stops, extending take-profits, and custom tracking functions
• Technical analysis — built-in pandas-ta integration plus optional TA-Lib support
• Multi-process execution — run independent bots in parallel with Bot.process_pool()
• JSON configuration — centralise credentials and settings in aiomql.json
• Contributed extensions — pre-built traders (SimpleTrader, ScalpTrader), strategies (Chaos), and specialised symbols (ForexSymbol)

Requirements

• Python ≥ 3.13
• Windows (MetaTrader 5 terminal requirement)
• A MetaTrader 5 trading account

Installation

pip install aiomql

Optional extras:

# TA-Lib technical indicators
pip install aiomql[talib]
Optional (Cython, Numba, tqdm)
pip install aiomql[optional]
Both
pip install aiomql[all]

Quick Start

Configuration

Create an aiomql.json file in your project root:

{
  "login": 12345678,
  "password": "your_password",
  "server": "YourBroker-Demo"
}

All settings can also be set programmatically via the singleton Config class:

from aiomql import Config
config = Config(login=12345678, password="your_password", server="YourBroker-Demo")

Using the MetaTrader Interface

import asyncio
from aiomql import MetaTrader
async def main():     async with MetaTrader() as mt5:         # Account information         account = await mt5.account_info()         print(account)
# Available symbols         symbols = await mt5.symbols_get()         print(f"{len(symbols)} symbols available")
asyncio.run(main())

Building a Trading Bot

1. Define a Strategy

Subclass Strategy and implement the trade() method. Parameters declared in the parameters dict become instance attributes and can be overridden at construction time.

# strategies/ema_crossover.py
from aiomql import Strategy, ForexSymbol, TimeFrame, Tracker, OrderType, Sessions, Trader, ScalpTrader
class EMAXOver(Strategy):     ttf: TimeFrame     tcc: int     fast_ema: int     slow_ema: int     tracker: Tracker     interval: TimeFrame     timeout: int
parameters = {         "ttf": TimeFrame.H1,         "tcc": 3000,         "fast_ema": 34,         "slow_ema": 55,         "interval": TimeFrame.M15,         "timeout": 3  60  60,     }
def init(self, *, symbol: ForexSymbol, params: dict | None = None,                  trader: Trader = None, sessions: Sessions = None,                  name: str = "EMAXOver"):         super().init(symbol=symbol, params=params, sessions=sessions, name=name)         self.tracker = Tracker(snooze=self.interval.seconds)         self.trader = trader or ScalpTrader(symbol=self.symbol)
async def find_entry(self):         candles = await self.symbol.copyratesfrom_pos(             timeframe=self.ttf, count=self.tcc         )         candles.ta.ema(length=self.fast_ema, append=True)         candles.ta.ema(length=self.slow_ema, append=True)         candles.rename(             **{f"EMA{self.fastema}": "fast_ema",                f"EMA{self.slowema}": "slow_ema"},             inplace=True,         )
fas = candles.talib.above(candles.fastema, candles.slow_ema)         fbs = candles.talib.below(candles.fastema, candles.slow_ema)
if fas.iloc[-1]:             self.tracker.update(order_type=OrderType.BUY, snooze=self.timeout)         elif fbs.iloc[-1]:             self.tracker.update(order_type=OrderType.SELL, snooze=self.timeout)         else:             self.tracker.update(order_type=None, snooze=self.interval.seconds)
async def trade(self):         await self.find_entry()         if self.tracker.order_type is None:             await self.sleep(secs=self.tracker.snooze)         else:             await self.trader.place_trade(                 ordertype=self.tracker.ordertype, parameters=self.parameters             )             await self.delay(secs=self.tracker.snooze)

2. Wire It Up with a Bot

import logging
from aiomql import Bot, ForexSymbol, OpenPositionsTracker
from strategies.ema_crossover import EMAXOver
logging.basicConfig(level=logging.INFO)
def main():     symbols = [ForexSymbol(name=s) for s in ["EURUSD", "GBPUSD", "USDJPY"]]     strategies = [EMAXOver(symbol=sym) for sym in symbols]
bot = Bot()     bot.add_strategies(strategies)
# Optionally track open positions on a separate thread     bot.add_coroutine(         coroutine=OpenPositionsTracker(autocommit=True).track,         onseparatethread=True,     )
bot.execute()  # synchronous entry point (blocks until shutdown)
if name == "main":     main()

Tip: Use await bot.start() instead of bot.execute() if you're already inside an async context.

3. Trading Sessions

Restrict when a strategy trades by passing Sessions:

from datetime import time
from aiomql import Session, Sessions, ForexSymbol, Chaos
london = Session(name="London", start=time(8, 0), end=time(16, 0)) new_york = Session(name="New York", start=time(13, 0), end=time(21, 0))
sessions = Sessions(sessions=[london, new_york]) strategy = Chaos(symbol=ForexSymbol(name="USDJPY"), sessions=sessions)

4. Multi-Process Execution

Run completely independent bots in separate processes:

from aiomql import Bot
def run_forex():     bot = Bot()     # ... add forex strategies ...     bot.execute()
def run_crypto():     bot = Bot()     # ... add crypto strategies ...     bot.execute()
Bot.processpool(processes={runforex: {}, runcrypto: {}}, numworkers=2)

Project Structure

src/aiomql/
├── core/               # Low-level infrastructure
│   ├── _core.py        #   MT5 function definitions & async wrappers
│   ├── meta_trader.py  #   MetaTrader singleton (init, login, symbol/order calls)
│   ├── config.py       #   Singleton Config (JSON + programmatic settings)
│   ├── constants.py    #   Enums (TimeFrame, OrderType, TradeAction, …)
│   ├── models.py       #   Data models (SymbolInfo, AccountInfo, TradeRequest, …)
│   ├── base.py         #   _Base metaclass (attribute helpers, MT5 access)
│   ├── db.py           #   SQLite trade-results database
│   ├── store.py        #   In-memory shared state store
│   ├── state.py        #   State management
│   ├── task_queue.py   #   Async task queue for scheduled work
│   ├── errors.py       #   Error definitions
│   ├── exceptions.py   #   Custom exceptions (OrderError, LoginError, …)
│   └── sync/           #   Synchronous MetaTrader wrapper
│
├── lib/                # High-level trading components
│   ├── bot.py          #   Bot orchestrator (strategy runner, process pool)
│   ├── executor.py     #   Thread/task executor for strategies
│   ├── strategy.py     #   Strategy base class (trade loop, sessions)
│   ├── symbol.py       #   Symbol (market data, ticks, rates)
│   ├── order.py        #   Order (check, send, margin, profit)
│   ├── trader.py       #   Trader (place_trade, SL/TP management)
│   ├── account.py      #   Account singleton
│   ├── candle.py       #   Candles collection (DataFrame + TA)
│   ├── ticks.py        #   Tick & Ticks (tick data collections)
│   ├── positions.py    #   Position querying & management
│   ├── history.py      #   Trade & order history
│   ├── ram.py          #   RAM (Risk Assessment & Money) manager
│   ├── sessions.py     #   Session & Sessions (time-window trading)
│   ├── terminal.py     #   Terminal info wrapper
│   ├── result.py       #   Trade result recording (CSV/JSON)
│   ├── result_db.py    #   Trade result recording (SQLite)
│   ├── trade_records.py#   Trade records management
│   └── sync/           #   Synchronous mirrors of lib modules
│
├── contrib/            # Community extensions
│   ├── strategies/     #   Chaos (random buy/sell demo)
│   ├── symbols/        #   ForexSymbol (pip & volume calculations)
│   ├── trackers/       #   Position & open-positions trackers
│   ├── traders/        #   SimpleTrader, ScalpTrader
│   └── utils/          #   StrategyTracker (Tracker)
│
├── ta_libs/            # Technical analysis (pandas-ta classic)
└── utils/              # Decorators, price helpers, process pool

API Documentation

See the full API Reference for detailed documentation of every module.

Testing

# Install dev dependencies
pip install -e ".[dev]"
Run the test suite
pytest tests

Contributing

Pull requests are welcome. For major changes, please open an issue first to discuss what you would like to change.

License

MIT
